Zinc Plated Link Chain ASTM80 Standard Link Chain Wholesale
1. ASTM80 Standard Link Chain Introduction
PROOF COIL ASTM80 (G30)
NOMINAL | WORKING LOAD | PROOF LOAD | MIN.BREA-KINGLOAD | WEIGHT | INSIDE | INSIDE | |||||||
inches | mm | kg | lb | kn | lb | kn | lb | kg | lb | mm | inches | mm | inches |
1/8 | 4 | 190 | 420 | 378 | 850 | 7.56 | 1,700 | 8.8 | 19 | 22.6 | 0.89 | 7.4 | 0.29 |
3/16 | 5.5 | 360 | 800 | 7.11 | 1,600 | 14.2 | 3,200 | 18.3 | 40 | 24.1 | 0.95 | 10.2 | 0.40 |
1/4 | 7.1 | 600 | 1,330 | 11.8 | 2,650 | 23.6 | 5,300 | 32.7 | 72 | 25.4 | 1.00 | 12.7 | 0.50 |
5/16 | 8.7 | 910 | 2,000 | 17.8 | 4,000 | 35.6 | 8,000 | 48.0 | 106 | 27.9 | 1.10 | 12.7 | 0.50 |
3/8 | 10.3 | 1,270 | 2,800 | 24.9 | 5,600 | 49.8 | 11,200 | 70.3 | 155 | 31.2 | 1.23 | 15.7 | 0.62 |
1/2 | 13.5 | 2,190 | 4,800 | 42.9 | 9,650 | 85.8 | 19,300 | 123 | 271 | 38.9 | 1.53 | 20.3 | 0.80 |
5/8 | 16.7 | 3,350 | 7,400 | 65.8 | 14,800 | 131.6 | 29,600 | 184 | 405 | 48.3 | 1.90 | 25.4 | 1.00 |
3/4 | 19.8 | 4,700 | 10,400 | 92J5 | 20,800 | 185.0 | 41,600 | 264 | 582 | 54.6 | 2.15 | 28.4 | 1.12 |
7/8 | 23 | 6,350 | 14,000 | 124.5 | 28,000 | 249.0 | 56,000 | 368 | 811 | 63.5 | 2.50 | 34.8 | 1.37 |
1 | 26.5 | 8,400 | 18,600 | 165.4 | 37,200 | 330.8 | 74,400 | 474 | 1045 | 69.9 | 2.75 | 38.1 | 1.50 |
HIGH TEST CHAIN ASTM80 (G43)
NOMINAL | WORKING LOAD | PROOF LOAD | MIN.BREA-KING LOAD | WEIGHT | INSIDE | INSIDE | |||||||
inches | mm | kg | lb | kn | lb | kn | lb | kg | lb | mm | inches | mm | inches |
1/4 | 7.1 | 1,180 | 2,600 | 19.1 | 4,300 | 345 | 7,750 | 36.3 | 80 | 21.8 | 0.86 | 10.2 | 0.4 |
5/16 | 8.7 | 1,770 | 3,900 | 28.4 | 6,400 | 51.6 | 11,600 | 50.4 | 111 | 26.7 | 1.05 | 12.2 | 0-48 |
3/8 | 10.3 | 2,450 | 5,400 | 39.6 | 8,900 | 72 | 16,200 | 72.6 | 160 | 30.3 | 1.19 | 14.7 | 0.58 |
1/2 | 13.5 | 4,170 | 9,200 | 68.0 | 15,300 | 122.7 | 27,600 | 128.6 | 284 | 36.0 | 1.43 | 19.1 | 0.75 |
TRANSPORT CHAIN ASTM80 (G70)
NOMINAL | WORKING LOAD | PROOF LOAD | MIN.BREA-KING LOAD | WEIGHT | INSIDE | INSIDE | |||||||
indies | mm | kg | lb | kn | lb | kn | lb | kg | lb | mm | inches | mm | inches |
1/4 | 7.1 | 1,430 | 3,150 | 27.8 | 6,300 | 56.0 | 12,600 | 34.0 | 75 | 21.8 | 0.86 | 11.4 | 0.45 |
5/16 | 8.7 | 2,130 | 4,700 | 41.8 | 9.400 | 83.6 | 18,800 | 50.4 | 111 | 25.6 | 1.01 | 11.7 | 0.46 |
3/8 | 10.3 | 2,990 | 6,600 | 58.7 | 13.200 | 117.4 | 26,400 | 71.0 | 156 | 30.2 | 1.19 | 14.0 | 0.55 |
2. Different Product Surface Available
Aluminum material surface | Stainless steel material surface | Steel material surface |
Clear Anodized | Polishing | Zinc plating |
Color Anodized | Passivating | Oxide black |
Sandblast Anodized | Sandblasting | Nickel plating |
Chemical Film | Laser engraving | Chrome plating |
Brushing | Electric pulse black | Carburized |
Polishing | Hot galvanized | |
Chroming | Powder Coated |
3. Product introduction
Material | STAINLESS STEEL AISI316, STAINLESS STEEL AISI304, STEEL ELECTRIC GALVANIZED, ZINC ALLOY |
Size | Different size available |
Surface | Polished or zinc plated or nickel or chromed or self-color |
Usage | marine, bag or pet accessories etc. |
MOQ | No MOQ |
Capacity | 100000pcs/Month |
Package | clean poly bags in cartons and then on pallets or as customer requirements |
Sample time | 3 days |
Lead time | 10-30 days based on the order quantity |
Payment Terms | 30% deposit in advance, 70% before shipment |
Payment methods | T/T or Western Union |
QC | 100% inspect before packing, Spot inspect before shipping |
After-sale services | 24 hours reply and free charge exchange goods |
We provide the premium quality products with competitive price for every customer! | |
4. Product Pakages&Shipping
Sea line, Express, Train line, trucks and airlines are all available!
5.Company Introduction&Production Introduction
a.Factory production room
b.Production Line
c. Product Inspection Machine&Tools
d. Storeroom&Contain Filling
6. FAQ
Do you accept customized products? Yes, We are acceptable for customized product and also offer design service for free. |
Will you charge the mould fee? We only charge the mould fee when a new mould is needed, but if your order quantity is big enough, we will refund the mould fee after the order. |
What about the terms of payment? T/T, L/C, Western Union, Visa and Wire transfer etc. |
What about your product MOQ? It depends on the product size, normally from 10 - 100 pieces |
What is the delivery time? Normally It takes 3 days for samples if we have the products in stock. For bulk order, it takes 10-30 days according to product size and quantity! |
For more detailed, please feel free to contact us. |
7.Contact
Mark Wang
International Sales Director
Qingdao Sino Summit Machinery Co., Ltd.
Add: Add: Room 401, Unit 2, Building 9, No. 412 Chongqing Middle Road, Licang District, Qingdao, China
Post Code: 266041
Skype: enjoyfreshair Tel:0086-13573263229
Mob:0086-13573263229 Whatsapp:008613573263229
Wechat: 008613573263229
http://www.sinosummit.cn
http://www.sinosummit.com.cn
